Phoenix-contact

PHOENIX CONTACT 2904600 ; QUINT4-PS/1AC/24DC/5 POWER SUPPLY UNIT Used

PHOENIX CONTACT 2904600 ; QUINT4-PS/1AC/24DC/5
Excl. Tax
Transport and Handling Information
Need more?

Need something we currently don't have available? Our sourcing team can help you find what you need

General
Brands:
PHOENIX CONTACT
HAN:
2904600 ; QUINT4-PS/1AC/24DC/5
Condition:
Used
Logistics
Weight:
0.65kg
Country of Manufacture:
Taric-Code:
85044090

The Phoenix Contact QUINT POWER QUINT4-PS/1AC/24DC/5 is a high-performance DIN-rail power supply delivering a stabilized 24 V DC at 5 A for demanding industrial automation and control applications. With Selective Fuse Breaking (SFB) technology for reliable branch protection, an adjustable U/I Advanced output characteristic for dynamic loads, and an NFC interface for fast parameterization and diagnostics, it ensures maximum availability in modern control cabinets.

Its wide-range input supports single-phase AC 50/60 Hz as well as 110–250 V DC, while robust transient protection with varistor and gas discharge arrestor, inrush current limiting (typ. 14 A), and comprehensive electronic output protection (OVP ≤ 32 V DC, short-circuit-proof, reverse-energy-resistant ≤ 35 V DC) safeguard equipment. High efficiency (typ. 88.8% at 120 V AC), an MTBF > 1,532,000 h (25 °C), and an extended operating temperature from -25 to +70 °C with derating above 60 °C make it suitable for machine building, process control, and energy systems. Push-in connections accelerate installation, and parallel or series operation supports redundancy concepts.

Engineered for uptime and safety compliance (IEC/EN standards including IEC 61010 and EN 61204-3), this 24 V DC industrial power supply combines rapid fuse tripping via SFB, NFC-enabled commissioning, and stable power reserves to reduce downtime, and it is backed by a 1-year warranty to further support operational continuity in critical environments.

  • Brand: Phoenix Contact
  • Series: QUINT POWER
  • Model: QUINT4-PS/1AC/24DC/5 (2904600)
  • Output: 24 V DC / 5 A (120 W)
  • Input voltage: AC 1-phase 50/60 Hz; 110–250 V DC
  • Output characteristic: U/I Advanced
  • Connection type: Push-in terminals
  • Protection rating: IP20
PHOENIX CONTACT 2904600 ; QUINT4-PS/1AC/24DC/5 PRIMARY-SWITCHED QUINT POWER POWER SUPPLY WITH FREE CHOICE OF OUTPUT CHARACTERISTIC CURVE, SFB (SELECTIVE FUSE BREAKING) TECHNOLOGY, AND NFC INTERFACE, INPUT: 1-PHASE, OUTPUT: 24 V DC/5 A
