PHOENIX CONTACT 2902829 ; MINI MCR-SL-UI-I-LP-NC SIGNAL CONDITIONER New

PHOENIX CONTACT 2902829 ; MINI MCR-SL-UI-I-LP-NC
Excl. Tax
Transport and Handling Information
Need more?

Need something we currently don't have available? Our sourcing team can help you find what you need

General
Brands:
PHOENIX CONTACT
HAN:
2902829 ; MINI MCR-SL-UI-I-LP-NC
Condition:
New
Logistics
Weight:
0.10kg
Country of Manufacture:
EAN:
4046356682350
Taric-Code:
85389091

The Phoenix Contact MINI MCR-SL-UI-I-LP-NC signal conditioner is a compact loop-powered isolating amplifier for reliable galvanic isolation and conversion of standard analog signals in control cabinets and process installations. Thanks to its slim 6.2 mm housing and DIN rail mounting, this MINI Analog module is well suited to space-saving industrial signal interfacing and stable transmission of measurement values.

Configured via DIP switches, the single-channel isolating amplifier accepts voltage signals from 0 to 1000 mV and current signals from 0 to 40 mA, converting them to a 4 to 20 mA output. The unit is supplied from the output side, requires no external power supply, and combines 2-way isolation, an approximate 16 ms response time and screw connection technology for dependable installation in industrial automation panels.

For panel builders, OEMs and maintenance professionals, this Phoenix Contact isolating amplifier offers a practical solution for signal isolation, signal conversion and interference-resistant transmission in demanding electrical applications, while the included 1-year warranty provides additional assurance for daily operation and replacement planning.

  • Brand: Phoenix Contact
  • Series: MINI Analog
  • Model: MINI MCR-SL-UI-I-LP-NC
  • Input signal: 0 to 1000 mV / 0 to 40 mA
  • Output signal: 4 to 20 mA
  • Supply: Loop-powered, no external supply required
  • Protection rating: IP20
  • Connection type: Screw connection
PHOENIX CONTACT 2902829 ; MINI MCR-SL-UI-I-LP-NC 2-WAY LOOP-POWERED ISOLATING AMPLIFIER (SUPPLIED ON THE OUTPUT SIDE), CAN BE CONFIGURED VIA DIP SWITCHES, WITH SCREW CONNECTION TECHNOLOGY AND STANDARD CONFIGURATION.
