416943 (1)

PHOENIX CONTACT 2902040 ; MINI MCR-2-UI-UI-PT New

PHOENIX CONTACT 2902040 ; MINI MCR-2-UI-UI-PT
Excl. Tax
Transport and Handling Information
Need more?

Need something we currently don't have available? Our sourcing team can help you find what you need

General
Brands:
PHOENIX CONTACT
HAN:
2902040 ; MINI MCR-2-UI-UI-PT
Condition:
New
Logistics
Weight:
0.10kg
Country of Manufacture:
Taric-Code:
85389091

The Phoenix Contact MINI MCR-2-UI-UI-PT is a compact 3-way isolation amplifier for reliable galvanic isolation and conversion of uni- and bipolar analog signals in industrial control cabinets. Designed for demanding measurement and process automation applications, this MINI Analog Pro module supports stable signal transmission between sensors, controllers and PLC input cards.

The device offers one configurable input and one configurable output for voltage and current signals, with measuring ranges selectable via DIP switches. Push-in connection technology speeds up wiring, while the 6.2 mm housing, 24 V DC supply and 3 kV AC test voltage make it suitable for space-saving DIN rail installations with high signal integrity and robust EMC performance.

For machine builders, panel builders and maintenance teams, this Phoenix Contact signal conditioner provides a dependable solution for analog signal isolation, interference reduction and standardized signal adaptation, supplied with the added assurance of a 1-year warranty.

  • Brand: Phoenix Contact
  • Series: MINI Analog Pro
  • Model: MINI MCR-2-UI-UI-PT
  • Product type: Input isolation amplifier
  • Input signal: 0 V to 5 V or 0 mA to 20 mA via DIP switches
  • Output signal: 0 V to 5 V or 0 mA to 20 mA via DIP switches
  • Supply voltage: 9.6 V DC to 30 V DC
  • Connection type: Push-in connection
PHOENIX CONTACT 2902040 ; MINI MCR-2-UI-UI-PT
