308850 (1)

PHOENIX CONTACT 2737494 ; IBS PCI 104 SC-T New

PHOENIX CONTACT 2737494 ; IBS PCI 104 SC-T
Excl. Tax
Transport and Handling Information
Need more?

Need something we currently don't have available? Our sourcing team can help you find what you need

General
Brands:
PHOENIX CONTACT
HAN:
2737494 ; IBS PCI 104 SC-T
Condition:
New
Logistics
Weight:
0.70kg
Country of Manufacture:
Taric-Code:
85389091

The PHOENIX CONTACT IBS PCI 104 SC-T is a compact PC control card in PCI-104 format that connects an INTERBUS fieldbus to an IBM-compatible PC with a PCI-104 slot. Engineered for industrial automation and machine building, it delivers reliable master functionality for both retrofit and new INTERBUS deployments, ensuring stable communication and streamlined integration in control cabinets.

Operating as an INTERBUS master without galvanic isolation, the card handles up to 8192 bits of process data and supports up to 126 stations with parameter channel. Switchable transmission rates of 500 kbit/s or 2 Mbit/s over copper ensure optimal performance, while status LEDs (MREADY and INTERBUS state) and local diagnostics accelerate commissioning. Engineering and diagnostics are supported via CMD (from version 4.62) and DIAG+ (from version 1.0x); the HFI application interface and a Windows NT driver with Plug and Play IRQ integration facilitate seamless incorporation into IBM-compatible systems. Power is supplied with 5 V DC (±5%) through the PC-104 bus with a typical current draw of 0.7 A and max. power dissipation of 3.5 W; the unit is intended for IP20 environments with an operating temperature range of 0 to 55 °C according to EN 60204-1.

With a proven INTERBUS stack, clear LED diagnostics, and a robust PCI-104 design, the IBS PCI 104 SC-T provides dependable fieldbus connectivity and consistent throughput for OEMs and maintenance teams, and to underscore lifecycle confidence it is supplied with a 1-year warranty.

  • Brand: Phoenix Contact
  • Model: IBS PCI 104 SC-T (2737494)
  • Form factor: PCI-104, 32-bit, 33 MHz
  • Fieldbus: INTERBUS master, copper
  • Data rate: 500 kbit/s / 2 Mbit/s (switchable)
  • Supply voltage: 5 V DC (±5%) via PC-104 bus
  • Protection rating: IP20
  • Operating temperature: 0 to 55 °C
PHOENIX CONTACT 2737494 ; IBS PCI 104 SC-T
