The Mitsubishi Electric FR-D840-0.75K-022-EPB-60 is a compact frequency inverter engineered for dependable 400 V-class motor control in industrial automation. Delivering 0.75 kW rated motor power and seamless integration with industrial Ethernet networks including PROFINET, it suits pumps, fans, conveyors, and general machinery, combining space-saving design with a conformal-coated build for robust performance in control panels.

Advanced magnetic flux vector, PM sensorless vector, and V/F control ensure stable torque and efficient speed regulation across a wide 0.2 to 590 Hz range. The drive operates on a 3-phase 380 to 480 V AC supply (323 to 528 V allowable), provides 2.2 A ND output current, and incorporates Safe Torque Off (STO) for functional safety. Practical features include a built-in 4-digit LED display, spring-clamp terminals for fast wiring, 5 digital inputs, 2 analog inputs, 1 analog output, 1 transistor output plus 1 relay output, an Ethernet port with PROFINET, CC-Link IE TSN/Field Basic, Modbus/TCP, USB Type-C for easy parameterization, and a 100% ED brake chopper; protection rating is IP20.

Designed to reduce commissioning time and enhance energy efficiency, this variable frequency drive supports modern PLC and SCADA connectivity while meeting CE and RoHS requirements. To support long-term operation and procurement confidence, it is supplied with a 1-year warranty as part of a reliable lifecycle and service concept.

• Brand: Mitsubishi Electric
• Series: FR-D800 Series
• Model: FR-D840-0.75K-022-EPB-60
• Rated motor power (ND): 0.75 kW
• Supply voltage: 3-phase 380 to 480 V AC (323 to 528 V allowable)
• Output current (ND): 2.2 A
• Network interfaces: PROFINET, CC-Link IE TSN, CC-Link IE Field Network Basic, Modbus/TCP
• Protection rating: IP20
