The Mitsubishi Electric FX5U-32MR/DS CPU from the MELSEC iQ-F series is a compact, high-performance PLC engineered for machine automation, OEM projects, and panel builders. It combines 16 DC inputs, 16 relay outputs, and integrated Ethernet and RS-485 to streamline control, monitoring, and maintenance across industrial applications.

Operating on 24 V DC, the FX5U platform delivers fast instruction execution (34 ns LD/MOV) with a robust 64K-step FLASH program memory. Two onboard analog input channels cover essential measurement tasks, while the system scales up to 512 I/O points for future expansion. Relay outputs accommodate mixed-voltage loads, and the built-in Ethernet and RS-485 ports support engineering access, diagnostics, and field connectivity. Designed for harsh environments with an operating range of -20 to +55 °C and compliance to CE, UL/cUL, and UKCA, plus marine approvals (ABS, BV, DNV GL, KR, LR, NK, RINA), it fits demanding control architectures.

Choose the FX5U-32MR/DS to reduce cabinet space, simplify wiring, and improve uptime in both new and retrofit installations, backed by a 1-year warranty that supports confident deployment and lifecycle management.

• Brand: Mitsubishi Electric
• Series: MELSEC iQ-F
• Model: FX5U-32MR/DS
• Supply voltage: 24 V DC
• Digital inputs: 16
• Digital outputs: 16 relay
• Analog inputs: 2
• Communication: 1x Ethernet, 1x RS-485
