The Mitsubishi Electric FR-D820-7.5K-318-60 is a compact frequency inverter in the FR-D800 series, designed for 200 V-class three-phase applications up to 7.5 kW. It delivers reliable variable speed control for induction motors in pumps, fans, conveyors, and general automation, combining robust performance with a space-saving IP20 design to support efficient panel layouts and fast deployment.

With a frequency range from 0.2 to 590 Hz and advanced magnetic flux vector and V/F control, the drive ensures precise torque and stable speed regulation under dynamic loads. Safety is enhanced via integrated Safe Torque Off (STO). Commissioning is streamlined with a built-in 4-digit LED interface and USB Type-C, while RS-485 supports Modbus RTU alongside CC-Link IE Field Network Basic and CC-Link IE TSN for seamless PLC integration. Five digital inputs, two analog inputs, one analog output, one transistor output, and one relay output provide flexible I/O via spring-clamp terminals, and a 100% ED brake chopper capability supports demanding deceleration profiles. For EMC compliance and harmonic mitigation, external EMC filtering and a DC choke can be added as required.

Whether for retrofit or new installations, this VFD helps reduce energy consumption and maintain process quality with dependable, low-maintenance operation, and it is supplied with a 1-year warranty to provide added assurance in critical electrical engineering environments.

• Brand: Mitsubishi Electric
• Series: FR-D800 SERIES
• Model: FR-D820-7.5K-318-60
• Supply voltage: 200 to 240 V AC (allowable 170 to 264 V), 3-phase
• Rated motor power (ND): 7.5 kW
• Rated output current (ND): 31.8 A
• Protection rating: IP20
• Communication protocols: Modbus RTU, CC-Link IE Field Network Basic, CC-Link IE TSN
