BECKHOFF EL3062 New

BECKHOFF EL3062
Tell us what you need?

If this product is not available right now, our sourcing team can help find an alternative or create a special order for you.

Need more?

Need something we currently don't have available? Our sourcing team can help you find what you need

General
Brands:
BECKHOFF
HAN:
EL3062
Condition:
New
Logistics
Weight:
0.10kg
Country of Manufacture:
Taric-Code:
85389091

The Beckhoff EL3062 EtherCAT Terminal delivers precise 2-channel analog voltage input for EtherCAT-based industrial automation systems. This compact module ensures reliable acquisition of 0…10 V signals, making it ideal for process monitoring and control in machinery and manufacturing environments.

With 12-bit resolution (16-bit including sign), single-ended inputs, and a measurement accuracy of < ±0.3% relative to full scale, the EL3062 features configurable multiplex conversion times from 0.625 ms, activatable FIR/IIR filters, and limit value monitoring. Powered directly via the E-bus, it provides 500 V electrical isolation between E-bus and signal voltage, IP20 protection, and compliance with CE, ATEX, and IECEx standards for versatile deployment.

Enhance your EtherCAT network's performance with the robust Beckhoff EL3062, supported by a 1-year warranty to ensure dependable operation and minimal downtime in demanding B2B applications.

  • Brand: Beckhoff
  • Model: EL3062
  • Number of inputs: 2 (single-ended)
  • Signal voltage: 0…10 V
  • Resolution: 12 bit
  • Power supply: via the E-bus
  • Protection rating: IP20
  • Electrical isolation: 500 V (E-bus/signal voltage)
